Geometry and Mensuration: Level 1 Test 6

This is an assessment test.
To draw maximum benefit, study the concepts for the topic concerned.
Kindly take the tests in this series with a pre-defined schedule.

Geometry and Mensuration: Level 1 Test 6

Please wait while the activity loads.
If this activity does not load, try refreshing your browser. Also, this page requires javascript. Please visit using a browser with javascript enabled.

If loading fails, click here to try again

Question 1

A solid metallic sphere of radius r is converted into a solid right circular cylinder of radius R. If the height of the cylinder is twice the radius of the sphere, then

A	R = r
B	$\displaystyle R=\text{ }r\sqrt{\frac{2}{3}}$
C	$\displaystyle R=\sqrt{\frac{2r}{3}}$
D	$\displaystyle R=\frac{2r}{3}$

Question 1 Explanation:

$\begin{array}{l}\frac{4}{3}\pi {{r}^{3}}=\pi {{R}^{2}}\times 2r\\=>\frac{2}{3}{{r}^{2}}={{R}^{2}}\\=>R=\sqrt{\frac{2}{3}r}\end{array}$

Question 2

The radius of a circle is twice the side of a square of area 196 sq.cm. Length of a rectangle is twice diameter of the circle. What is the perimeter of the rectangle if its breadth is haft the length of the rectangle?

A	244 cm
B	168 cm
C	336 cm
D	Cannot be determined

Question 2 Explanation:

Side of the square = 14 cm.
Radius of the circle = 28 cm.
Diameter of the circle = 56 cm.
Length of the rectangle = 112 cm.
Breadth =1/2 x 112 = 56cm
Perimeter of the rectangle = 2(112+56) = 336 cm.
Correct option is (c)

Question 3

The smallest side of a right angled triangle is 6 cm, and second largest side is 8 cm. The side of a square is thrice the largest side of the triangle. What is the length of the diagonal of the square?

A	30√2 cm
B	60√2 cm
C	30 cm.
D	Cannot be determined

Question 3 Explanation:

$\begin{align} & The\,\,third\,\,side=\sqrt{({{8}^{2}}+{{6}^{2}})}=\sqrt{(64+36)}=10 \\ & The\,\,side\,\,of\,\,the\,\,square=3\times 10=30\,cm \\ & The\,\,length\,\,of\,\,the\,\,diagonal\,\,is\,\,30\sqrt{2}\,cm \\ & Correct\,\,option\,\,is\,\,(a) \\ \end{align}$

Question 4

In the figure there are two rectangles ABCD and DEBG, each of length 7 cm and width 3 cm. The area of shaded region, in cm, is approximately

A	12
B	10
C	8
D	4

Question 4 Explanation:

The shaded region covers roughly half of the rectangle.
A bit more accurate measurement will be slightly more than half the rectangle.
Thus the shaded region >1/2 x 7x3 = 10.5 cm²
Thus the closest option greater than 10.5

Question 5

Height of a cylindrical jar is decreased by 36%. By what percent must the radius be increased so that there is no change in its volume?
